• M02-Mini200
  • M02-Mini200

    Intel TwinLake SSD up to 2TB with 5USB Support Windows 11I
    Product   FormMini PC
    Dimensions202*201*55.5mm
    WeightTBD
    MaterialPlastic
    Surface   processTBD
    Standard   ConfigurationDC   12V/5A


    • 0.00
      0.00
Product Description
Intel TwinLake SSD up to 2TB with 5USB Support Windows 11I
Product   FormMini PC
Dimensions202*201*55.5mm
WeightTBD
MaterialPlastic
Surface   processTBD
Standard   ConfigurationDC   12V/5A





Hardware   Configuration
 TypeDescriptions
ProcessorCPUIntel   TwinLake N150
GPUIntel®   UHD  Graphics
MemoryRAM1X   SO-DIMM DDR4 supporting up to 16GB
ROM1XM.2   SSD(2242 2260 2280) Support SATA/PCIE
I/OUSB   interface2 x USB2.0/3.0 (Front)
Type C1 x Type-C Full function    or 1 x Type-C USB 2.0 data only (Front)
Power Button1 x Power Button(Front)
Headphone jack1 x Audio Jack(Front)
Power connector1   x CLRCOMS (Rear)
HDMI interface1   x HDMI 2.0 (Rear)
DP    interface1   x VGA (Rear)
USB 2.04   x USB2.0/3.0(Rear)
AUDIO IN/OUT1x   AUDIO IN/OUT
RJ451   x RJ45 1000M Ethernet (Rear)
  Software Configuration
 TypeDescriptions
Operating SystemOperating   system versionWindows   11 Pro 64-bit
    Windows 11 Home 64-bit
TPMModuleF-TPM
  features
 TypeDescriptions
Certificate/CE/FCC/CCC/Rosh
Running scoresoftwareTDB
