    11.6" Intel Jasper Lake with 3USB Military-Grade Durability
    Military-Grade Durability
    (MIL-STD 810H)

    360 degrees rotation angle (convertible)

    Rotated Cam /Privacy Shutter

    Snap-Safe Keycap / WiFi & Power LED Indicator

    IP54 Protection

    • 0.00
      0.00
Product Description

11.6" Intel Jasper Lake with 3USB Military-Grade Durability
Military-Grade Durability
(MIL-STD 810H)

360 degrees rotation angle (convertible)

Rotated Cam /Privacy Shutter

Snap-Safe Keycap / WiFi & Power LED Indicator

IP54 Protection




 LCD

 11.6”TN/IPS 1366 x 768 touch   panel

 11.6"   FHD 1920 x 1080   touch panel  (optional)

CPU

Jasper Lake Intel® Celeron®

Processor: N4500/N5100/N6000

Silver Pentium N6000 (6W)

Memory

Socket   *1   or onboard: up   to 16G

Storage

 eMMC:   64G/ 128GB  ; M.2 SSD up   to 512G

 WLAN

 Wi-Fi 5+BT5.0   /Wi-Fi   6+BT5.2   /4G LTE   (Optional)

Battery

41.8W 7.6V 2S1P 5500mAh

AC adapter DC

24W, 12V   2A

Camera

 2M Rotated with privacy shutter

I/O Port

 1*DC-In (3.5Ø)

 2*USB   3.2 Type A

 1*USB   3.2 Gen1   Type C   (Data only)

 1*HDMI A type

 1*RJ45 (Optional)

 1*Micro SD card reader

 1*Combo audio jack   for MIC/headphone

 1*SIM cardslot   (Optional)

 1*Kensington Lock

Dimension

293*210.9*22.7mm
